PYF08A MY2 MY2N-J 8-Pin Relay Socket Base

Performance parameters

Performance parameters

Tolerance±0.2

Product Overview

 A DIN rail base for 8-pin relays like MY2, MY2N-J. It connects circuits with plug-and-play design, widely used in automation, power distribution and home appliances.

Product Features

① Modular plug-in structure supporting both DIN rail mounting and screw fixing.

② Conductive terminals realize stable contact with high insulation strength for safe operation.

③ The flame-retardant and heat-resistant housing features anti-vibration & anti-loosening performance and easy replacement.

④ Simple maintenance helps reduce overall operation and maintenance costs.

Working Principle

① Operation Mode: Energized coil generates electromagnetic force to switch contacts on and off. ② Control Logic: The base transmits signals to power the coil, and contacts control the load. ③ Signal Conversion: Passive transfer for isolation and transmission of electrical signals.

Materials & Structure

① The housing is made of flame-retardant PC material with excellent insulation and impact resistance.

② Terminals adopt silver-plated copper alloy, featuring good conductivity and arc resistance.

③ Standard 8-pin layout, equipped with DIN rail buckles and screw wiring structure.

Industry Solutions

① Widely used in industrial control, machine tools, power distribution, HVAC and smart home industries.

② Adopt standardized and modular wiring to solve problems such as messy wiring and difficult component replacement.

③ Effectively improve equipment stability, reduce maintenance difficulty and boost maintenance efficiency.

OEM/ODM Capabilities

① Customization of terminal layout, silk printing and packaging is available.

② Electrical parameters and flame retardant rating can be adjusted to match special relay pins.

③ We provide one-stop customized service from scheme design to mass production.

Customization Process

① Customer submits customized requirements

② Technical evaluation and quotation

③ Solution confirmation and sample production

④ Comprehensive sample testing

⑤ Mass production after sample approval

⑥ Packaged delivery and after-sales support

Production Capacity

① Equipped with standard workshops and automatic assembly lines for relay base accessories.

② Sufficient monthly capacity to support large orders as well as small-batch flexible production.

③ Flexible scheduling ensures stable delivery to meet varied customer lead time requirements.

Quality Control

① Implement full-process quality inspection, including incoming inspection, in-process patrol inspection and finished product inspection.

② Set key quality control points, isolate and trace defective products.

③ All relay bases undergo complete performance testing before delivery to guarantee stable quality.

Testing Equipment

① Equipped with professional testing instruments for dielectric strength, contact resistance and mechanical life.

② High-low temperature test equipment is available to conduct reliability tests under various working conditions.

③ Flame retardant testers are used to verify fire resistance indicators.

④ Carry out comprehensive tests on electrical performance, mechanical performance, environmental adaptability and flame retardant property.

Certifications

① Products have obtained international certifications including CE and RoHS.

② Production is managed in accordance with ISO quality management system.

③ Eco-friendly compliant materials with controlled hazardous substances.

④ Meet market access standards for domestic and overseas markets.

Production Process

① Raw material inspection to control quality at the source.

② Terminal stamping and electroplating, housing injection molding.

③ Component assembly and crimping to finish relay base assembly.

④ Electrical performance testing to verify electrical indicators.

⑤ Finished product appearance inspection to eliminate defective items.

⑥ Packaging and warehousing of qualified products. All working procedures are traceable.

Packaging & Logistics

① Standard packaging with anti-static inner box and outer carton to protect relay bases.

② Custom branded packaging or neutral packaging is available.

③ The regular lead time is 3-7 days.

④ Multiple logistics options are supported to ensure safe transportation of goods.

Export Capabilities

① Products can be exported worldwide with mature export experience.

② We are familiar with customs declaration and international logistics operations.

③ Complete customs clearance documents and relevant certifications can be provided.

④ Multiple transportation modes including sea freight, air freight and land freight are available.

FAQ

Q: Which relays does this base fit?

A: It is compatible with standard 8-pin relays such as MY2, MY2N-J and HH52P. Please confirm pin definition matching before use.

Q: What are the working environment limits?

A: Operating temperature ranges from -35℃~+70℃. Avoid humid conditions, corrosive gas and strong vibration.

Q: How to complete wiring?

A: Connect control circuits and load circuits according to terminal marks. Keep wiring firm to prevent poor contact.

Q: What mounting methods are supported?

A: It supports standard DIN rail mounting and screw fixing, suitable for most electrical control cabinets.
